Drill Presses
FEATURES
  •  3/4 inch capacity, 12.5 amp motor, 350 RPM
  •  Solid state electronic switching
  •  Feedback speed control
  •  Line Lock-Out prevents tool from operating should
    voltage be restored to an interrupted line

SPECIFICATIONS
  • Voltage  120 AC
  • Amps  12.5
  • Drill Capacity  3/4 in.
  • No Load Speed  350 RPM
  • Cord Type  9 ft. Fixed
  • Construction Type  Grounded
  • Electronic Feedback  Yes
  • Tap Capacity  1 in.-14
  • Drill Point Pressure  1,630/1,670 lbs.
  • Adjustable Base  Yes
  • Drill Travel  11 in.
  • Chuck or Taper  Chuck
  • Tool Weight  70.0 lbs.
  • Shipping Weight  78.0 lbs.
INCLUDES
  • Electromagnetic Drill Press Base
  • 3/4 in. Motor
Adjustable Position
Electromagnetic Drill Press with
3/4 in. Motor - Model 4206-1
FEATURES
  •  Powerful 9.0 amp 1.1 max HP motor
  •  Light weight, only 26.5 lbs. with comfortable carrying
    handle
  •  Capacity to cut up to 1-1/2 in. diameter holes thru 2 in. steel
    with annular cutters, or 1/2 in. diameter holes, 4-1/4 in. deep
    with twist drill bits
  •  Strong two-coil magnet
  •  Two positions for feed handle - relocate without tools
  •  Simple two-button control panel - unobstructed by feed
    handle

SPECIFICATIONS
  • Voltage  120 AC
  • Amps  9.0
  • Drill Capacity  1/2 in.
  • No Load Speed  450 RPM
  • Cord Type  8 ft. Fixed
  • Construction Type  Grounded
  • Electronic Feedback  Yes
  • Tap Capacity  --
  • Drill Point Pressure  750 lbs.
  • Adjustable Base  No
  • Drill Travel  6.6 in.
  • Chuck or Taper  Weldon
  • Tool Weight  26.5 lbs.
  • Shipping Weight  46.0 lbs.
INCLUDES
  •  Lubricant Spray
    Bottle
  •  Nylon Safety Strap
  •  Two Hex Wrenches
Compact Electromagnetic Drill
Press Kit - 450 RPM Model 4270-21
FEATURES       1-1/4 inch capacity, 12.5 amp motor,
500/250 RPM
  •  Solid state electronic switching
  •  Feedback speed control
  •  Line Lock-Out prevents tool from operating should
    voltage be restored to an interrupted line

SPECIFICATIONS
  • Voltage  120 AC
  • Amps  12.5
  • Drill Capacity  1-1/4 in.
  • No Load Speed  500/250 RPM
  • Cord Type  9 ft. Fixed
  • Construction Type  Grounded
  • Electronic Feedback  Yes
  • Tap Capacity  1 in.-14
  • Drill Point Pressure  1,530/1,600 lbs.
  • Adjustable Base  Yes
  • Drill Travel  11 in.
  • Chuck or Taper  No. 3 MT
  • Tool Weight  72.0 lbs.
  • Shipping Weight  82.0 lbs.
INCLUDES
  • Electromagnetic Drill Press Base, Adjustable Position
  • No. 3 MT Motor
Adjustable Position
Electromagnetic Drill Press with
No. 3 Mt Motor - Model 4208-1
Available at
Hilltop Tool Rental
$125.00 / day
$ 99.00 / day
